Circuit Topology | FULL RANGE CLASSS D |
RMS POWER OUTPUT 2 OHM | 900W X 4CH |
RMS POWER OUTPUT 4 OHM | 550W X 4CH |
BRIDGED RMS POWER @ 4 OHM | 2100W X 2CH |
TOTAL HARMONIC DISTORTION | <0.3% |
S/N RATIO REF 1W AT 4 OHM | 90dB |
GAIN RANGE | 0.2-10V |
CROSSOVER RANGE | 40-4KHz |
FREQUENCY RANGE | 20-20KHZ |
